12X3200MM E21S Guillotine Shear QC11K is a high performance hydraulic plate shearing machine suitable for shearing metal plates with a maximum thickness of 12mm and a maximum width of 3200mm.
Parameters | Value |
Shear thickness (carbon steel) | 12mm |
Shear length | 3200mm |
Shear angle | 0.5°～2.5° adjustable (some models) |
Sheet strength | ≤450 N/mm² |
Back gauge stroke | 20～600mm (CNC adjustment) |
Number of strokes (per minute) | 8～12 times (depending on thickness) |
Main motor power | Usually 15 kW |
CNC system | ESTUN E21S controls back gauge, stroke, etc. |
- Control the back gauge position
- Easy programming, suitable for repeated production
- Power-off memory function
- Manual/automatic/semi-automatic mode
- Multiple programmable parameters (commonly 40 programs)
Adopts all-steel welded structure, and undergoes vibration aging or heat treatment to eliminate internal stress, ensuring that the machine body has good rigidity and stability.
Equipped with an international brand integrated hydraulic system, providing stable and reliable hydraulic drive, reducing the risk of hydraulic oil leakage.
Adopts vertical shearing design, adjustable shearing angle, reduces plate deformation, and improves shearing quality.
Equipped with ESTUN E21S CNC system, with the following functions:
Back gauge (X axis) electric control, high positioning accuracy.
Intelligent positioning and multi-step programming functions, can store multiple sets of processing parameters, improve production efficiency.
LCD display, friendly operation interface, easy to set and adjust parameters.
Equipped with a quick adjustment mechanism, the blade gap can be adjusted steplessly, which is convenient and fast.
Equipped with photoelectric protection device and safety fence to ensure the safety of operators.
QC11K 12X3200mm E21S guillotine shearing machine is widely used in sheet metal processing, aerospace, light industry, metallurgy, chemical industry, construction, shipbuilding, electrical appliances, automobiles, electric power and other industries. It is suitable for shearing various metal materials, such as ordinary steel plates, stainless steel plates, aluminum plates, etc. Welcome to inquire!
